Konica Sonimage MX1 Ultrasound

Konica Sonimage MX1 Ultrasound

• Triad Tissue Harmonic Imaging Konica Minolta uses a unique waveform control algorithm in the generation of its harmonic signals. This technology, implemented on Sonimage MX1, enables the system to balance penetration and resolution, guaranteeing clarity and homogeneity through the whole image, from the very shallow to the deeper areas

• Dual Sonic TechnologyKonica Sonimage MX1 Ultrasound uses a unique algorithm, enabling the transmission of two waveforms, according to the focusing depth. In combination with T²HI, Dual Sonic forms the high quality of THI signal around the center of the ultrasound beam in the receiving area, resulting in a suppression of the acoustic noise and optimal image from deep to superficial.

• Enhanced MobilityWith its 4,5 Kg weight (including battery), Sonimage MX1 is very versatile and can easily suit different clinical environments and workflows. In office (on desk stand) At the point of care (standalone at the patient’s site) In hospital (on pole cart, through different departments) Real mobile (with suitcase or backpack) The 2 Hours Operation capability enhances the added value of Sonimage MX1 in Point of Care environments.
• High Accuracy / Diagnostic ConfidenceThe imaging and its quality are at the base of any reliable diagnosis and accurate procedures. Sonimage MX1 offers real diagnostic confidence and high accuracy in combination with a very compact and portable design.
• Intuitive OperationSonimage MX1 implements a very straightforward interface, based on the combination of a simplified console and touch screen.
• “Made in Japan” Ultrasound TransducersAll Sonimage MX1 probes are proudly designed and manufactured in Japan, by Konica Minolta. The Multi-Layer Technology as well as the quality of the materials used in the transducers contribute to the image quality, which is appreciated by the users at every scan.
• This function automatically adjusts imaging parameters, guaranteeing the optimal visualization in different scanning conditions.

• RA Rheumatoid Arthritis WorkflowRA Workflow is a unique Konica Minolta software integrated in your Konica Sonimage MX1 Ultrasound. This great tool based on DAS 28 protocol supports assessment of joints for Rheumatoid Arthritis. Provides a quick and clear overview of the examined patient’s joints. Customizable protocol to define the preferred acquisition sequence.

• SNV Simple Needle VisualizationSNV is a unique Minolta tool supporting interventional procedures under ultrasound-guidance. Enhances the needle and its tip, so you can see it more clearly. Supports both in-plane and out-plane approaches. Seeing the needle tip clearly enables safer and more efficient procedures.

• Workflow Efficiency

  Intuitive Operation

  Customizable touchscreen with the five most frequently used keys allows you to facilitate superior workflow and improve efficiency and throughput.

  Dual Sonic Technology

  As a result, it suppresses the acoustic noise to ensure the optimum image from deep area to superficial.
